What are the installation steps of wooden door locks?

Wooden door locks continue to develop and evolve, and continue to enhance their decorative and functional qualities.

• What should I pay attention to when installing the wooden door locks?

• How to determine wooden door lock in accordance with a good?

• What are the installation steps of wooden door locks?

What should I pay attention to when installing the wooden door locks?

When installing wooden door locks, only the end with the insurance can be removed to install, never remove the end with the key installation, it is best to read the instructions carefully. Special attention should be paid to the installation of handle locks: left open right open interchangeable in order to name cause the handle to carry upward when opening the door, because the current market in the high-grade handle locks have more left and right interchangeable function, no need to consider the direction of the door when buying.

1. First determine the installation location and punch the lock body into the lock hole and fix it with a screw.




2. then install the screw in the panel, then insert the square rod into the hole of the lock body, the square hole of the handle aligned with the linkage hole, install the panel components.




3. After installation, turn the inner and outer handles, insert the key and observe whether the latch can be freely extended and closed.

How to determine wooden door lock in accordance with a good?

Then install the latch box or latch plate on the door frame; after the initial installation, turn the outer handle, the inner handle to observe whether the oblique tongue can be smoothly retracted, extended; turn the back panel knob to feel whether the square tongue is smoothly retracted; insert the key to rotate back and forth to feel whether the square tongue is smoothly extended and retracted; tighten the assembly screws, repeat the above action, test several times, each action such as not smooth then loosen the screws, adjust the position and try again, until suitable to stop.

What are the installation steps of wooden door locks?

Drill the lock body installation holes; install the lock body into the holes in turn, correct and fix the screws, install the screw and connecting screw on the outer panel parts, insert the connecting square rod into the square rod hole of the lock body, align the square hole of the outer panel parts handle with the connecting square rod hole, install the outer panel parts; install the inner panel parts, align and fasten the screws; insert the lock head body into the lock body lock hole from the inside out; insert the screws from the lock body panel hole to align Insert the screw from the lock body panel hole to the threads of the lock body mounting hole and tighten it.
